The Hopper Magnet is an essential tool designed to safeguard machinery from iron contamination such as nuts, nails, and iron bits, ensuring uninterrupted and efficient operation. Available in four standard sizes, both round and square, these magnets can be chosen based on the dimensions and configuration of the hoppers.
Equipped with high-power magnetic rods, these magnets effectively block any iron materials from entering the machinery, guaranteeing a clean and smooth workflow. Additionally, special size hopper magnets are also available to cater to specific requirements and applications.
Inquiry| Type | CAT No. (Model no. as per catalogue of SVM) | DIM. A. mm | DIM. B. mm | DIM. H. mm | No. of Magnetic Rods & DIA |
|---|---|---|---|---|---|
| SQUARE | HM-200-S | 200 | 115 | 75 | 2 X 40mm |
| HM-250-S | 250 | 165 | 75 | 2 X 40mm | |
| HM-300-S | 300 | 215 | 75 | 3 X 40mm | |
| HM-375-S | 375 | 290 | 75 | 3 X 40mm | |
| ROUND | HM-200-R | 200 | 115 | 75 | 4 X 40mm |
| HM-250-R | 250 | 165 | 75 | 2 X 40mm | |
| HM-300-R | 300 | 215 | 75 | 3 X 40mm | |
| HM-375-R | 375 | 290 | 75 | 3 X 40mm |
